Cable protection system for sensors

Proxitron offers a comprehensive product portfolio with a wide range of options to protect cables and fiber optic
cables at extreme conditions. Robust protection hoses are available which are oil, grease and petrol resistant and/or
are installed in areas with extreme temperatures. These protection hoses are also appropriate for fiber optic cables.
You will find suitable accessories in our product range no matter what kind of cable protection you require.

Cable protection hose adapter HG2, article no. 9855B

For optical sensors with 3/4“ thread
Installation of cable protection screwing

Cable protection hose adapter HG6, article no. 9855F

For sensors with optical fiber cable
Installation of cable protection screwing

Cable protection hose adapter HG6, article no. 9828R

Proxitron cable protection hose adapter HG6

Air purge unit with air connection for lens cleaning usable with light barrier and infrared
sensor, with M55 thread for optionally Protection tubes.

Air blowing attachment OL 44, article no. 9829B

Blower attachment for optics OAC, OACF
Protection against contamination of the lens
Cooling the lens

Cable protection hose adapter HG6, article no. 9855F

For sensors with optical fiber cable
Installation of cable protection screwing

Replaceable protective glass SG 1 H, article no. 9809C

Proxitron Replaceable protective glass SG 1 H

Replaceable protective glass for optical sensors with stainless steel housing
PTFE
Ambient temperature up to 290 °C

Protective Glass SG 8, article no. 9809F

For optical sensors with housing Ø 57 mm
Ambient temperature up to 280 °C

Protective Glass SG 9, Artikel Nr. 9809G

For optical sensors with housing Ø 78 mm
Ambient temperature up to 280 °C

Tube OL19, article no. 9828A

For optical sensors with housing Ø 57 mm
Spot size narrowing
Detection of smaller objects with light barriers
Protecting the optics from thermal radiation
Stainless steel

Tube OL21, article no. 9828C
